Internal Gear Slewing Bearing

Brand DZE
Product origin Luoyang China
Delivery time 15 days
Supply capacity 2000sets/mouth

DZE company introduction.pdf

Internal gear series slewing bearings are mainly used in high-precision CNC machine tools and military radars. The internal gear surface precision reaches level 6, the minimum module M=1; the maximum outer diameter of production is 5000. DZE sales can reach 20 million US dollars, with a large amount of inventory, and can be shipped on the same day.

Product features

The inner ring (or outer ring) of the internal gear four-point contact ball slewing bearing is composed of two half rings, and the radius of curvature of the groove of the whole (or inner ring) is very small, so that the steel ball and the inner and outer rings are in contact at four "points", which not only increases the radial load capacity, but also can withstand large axial loads in two directions with a compact size.

The quality and high precision of our products will ensure that your machine runs smoothly and safely. Our product range includes roller bearings, gear bearings, cross roller bearings from standard slewing rings to slewing rings customized to your application requirements. Our design, development and research departments are equipped with state-of-the-art test benches and calculation software to provide you with innovative and suitable solutions at any time.

Single or double row ball bearings or roller bearings
Slewing rings with external gears, gear bearings, spur gears, helical gears or without gears
Steel, titanium, aluminum, etc.
Surface treatment and/or corrosion protection
Standard or specific seals
Lifetime lubricated rings, food-grade grease.

Internal gear slewing bearing effect diagram

Slewing bearing parameters

D	d	H	Weight	M	Z	DZE Model	Model
300	174.5	40	10	3	60	LYDZ 03-300	02 0245 00	STD
340	216	39	12	4	56	LYDZ 03-340	VI160288-N
340	216	39	12	4	56	LYDZ 03-340	12-16 0288/1-00306
380	235	54	26	4	56	LYDZ 03-380	013.20.310.04T
382	250	59	18	3.5	73	LYDZ 03-382	VI140326-V
385	217	55	24	4	56	LYDZ 03-385	02 0308 01	STD
386	225	56	22	5	47	LYDZ 03-386	12-20 0311/1-02202
408	222	70	48	5	40	LYDZ 03-408	013.25.315
410	256	39	24	4	66	LYDZ 03-410	12-16 0344/2-01873
417	225	56	21	5	47	LYDZ 03-417	92-20 0311/1-07203	法兰
418	225	56	21	5	47	LYDZ 03-418	92-20 0311/1-07202
422	247	50	29.5	5/7	50	LYDZ 03-422	16292001	XT
448	262	70	53	5	49	LYDZ 03-448	013.25.355
451	291	55	28	5	60	LYDZ 03-451	07 0380 01	STD
456	327	57.5	30	5	67	LYDZ 03-456	2787/327
486	332	39	24	4	85	LYDZ03-486-L	12-16 0420/1-00728
486	325	56	31	5	67	LYDZ 03-486	RKS.062.20.0414
486	325	56	31	5	67		VSI200414
486	325	56	31	5	67		32 0411 01	SLBP
486	332	39	23	4	85	LYDZ 03-486-L	VI160420-N
493	307	70	61	6	48	LYDZ 03-493	013.25.400
515	316	54	44	5	64	LYDZ 03-515	02 0422 00	STD
518	325	56	27.5	5	67	LYDZ 03-518-L	VLI200414-N
518	325	56	27.5	5	67		RK6-16N12
517	325	56	28	5	67		92-20 0411/07213	法兰
518	325	56	31	5	67		RKS.22 0411
518	325	56	28	5	67		92-20 0411/1-07212
518	325	56	31	5	67		22 0411 01	SL
519	326	56	28	5	67	LYDZ 03-519	HS6-16N1Z
520	324	52	47.7	5/7	65	LYDZ 03-520	16293001	XT
543	357	70	72	6	56	LYDZ 03-543	013.25.450
555	304	80	64	8	40	LYDZ 03-555	12-25 0555/1-04210
562	385	60	44	6	66	LYDZ 03-562	07 0489 11	STD
610	403	68	63	6	68	LYDZ 03-610	02 0520 00	STD
616	445	56	43	6	76	LYDZ 03-616	32 0541 01	SLBP
616	444	56	43	6	76	LYDZ 03-616	VSI200544-N
616	444	56	43	6	76		12-20 0541/1-02222
616	444	56	43	6	76		RKS.062.20.0544
648	326	56	41			LYDZ 03-648-L	RK6-22N1Z	法兰
648	445	56	41	6	76	LYDZ 03-648	RKS.22 0541
648	444	56	39	6	76		92-20 0541/1-07222
648	445	56	41	6	76		22 0541 01	SL
648	447	56	40	6	76		HS6-21N1Z
648	444	56	40.6	6	76		VLI200544N ZT
654.8	440	92	117	4	112	LYDZ 03-654.8	278790G2
654	428	70	81.7	4	69	LYDZ 03-654	16294001	XT
655	416	80	76	8	54	LYDZ 03-655	12-25 0655/1-04220
665	457	60	61	6	77	LYDZ 03-665	07 0573 00	STD
716	546	56	51	6	93	LYDZ 03-716	32 0641 01	SLBP
716	546	56	50	6	93		VSI200644-N
716	546	56	50	6	93		RKS.062.20.0644
726	546	56	50	6	93	LYDZ 03-726	12-20 0641/1-02232
735	498	72	102	4	80	LYDZ 03-735	16295001	XT
740	493	76	105	6	83	LYDZ 03-740	02 0626 01	STD
741	512	80	99	5	96	LYDZ 03-741	D2787/512
748	546	56	47.4	6	93	LYDZ 03-748	VLI200644N ZT
748	549	56	48	6	93		RK6-25N1Z	法兰
748	546	56	46	6	93		92-20 0641/1-07232
748	546	56	48	6	93		RKS.22 0641
748	546	56	48	6	93		22 0641 01	SL
749	549	56	48	6	93		HS6-25N1Z
755	512	80	102	8	66	LYDZ 03-755	12-25 0755/1-04230
771	541	70	96	6	91	LYDZ 03-771	07 0673 00	STD
602	367	80	78	5	74	LYDZ 03-602	013.30.500
602	368	80	78	6	62	LYDZ 03-602	014.30.500
647	444	56	39	6	76	LYDZ 03-647	92-20 0541/1-07223
662	425	80	94	5	86	LYDZ03-662	013.30.560
662	426.5	80	94	6	72	LYDZ03-662	014.30.560
732	528	80	110	6	83	LYDZ 03-732	013.30.630
747	546	56	46	6	93	LYDZ 03-747	92-20 0741/1-07233
812	608	80	120	6	86	LYDZ 03-812	013.30.710
816	649	56	58	6	110	LYDZ 03-816	32 0741 01	SLBP
816	648	56	57	6	110	LYDZ 03-816	12-20 0741/1-02242
835	578	82	130	8	73	LYDZ 03-835	02 0720 02	STD
847	648	56	52	6	110	LYDZ 03-847	92-20 0741/1-07243
848	648	56	54	6	110	LYDZ 03-848	VLI200744N
848	650	56	55	6	110	LYDZ 03-848	RK6-29N1Z	法兰
848	649	56	55	6	110	LYDZ 03-848	RKS.22 0741
848	649	56	55	6	110	LYDZ 03-848	22 0741 01	SL
848	650	56	55	6	110	LYDZ 03-848	HS6-29N1Z
855	610	80	119	10	63	LYDZ 03-855	12-25 0855/1-04240
868	656	77	103	8	82	LYDZ 03-868	12-22 0782/2-01218
870	633	72	123	4	101	LYDZ 03-870	16296001
871	634	70	113	8	80	LYDZ 03-871	07 0770 00	STD
914	614	89	142	2.5	62	LYDZ 03-914	HT10-30N1Z
916	736	56	69	8	94	LYDZ 03-916	12-20 0941/1-02252
916	736	56	70	8	94	LYDZ 03-916	32 0841 01	SLBP
922	678	100	256	8	80	LYDZ 03-922	013.40.800
935	674	82	150	8	85	LYDZ 03-935	02 0820 00	STD
936	738	75	100	6	124	LYDZ 03-936	12-22 0850/2-01501
947	736	56	63	8	94	LYDZ 03-947	92-20 0841/1-07263	法兰
948	740	56	67	8	94	LYDZ 03-947	RK6-33N1Z	法兰
948	736	56	65.2	8	94	LYDZ 03-948	VLI200844N
948	736	56	63	8	94	LYDZ 03-948	RKS.22 0841
948	736	56	63	8	94	LYDZ 03-948	22 0841 01	SL
948	736	56	63	8	94	LYDZ 03-948	92-20 0841/1-07252	法兰
950	740	56	65	8	94	LYDZ 03-948	HS6-33N1Z
955	710	80	137	10	73	LYDZ 03-955	12-25 0955/1-03210
960	706	75	144	8	89	LYDZ 03-960	07 0849 00	STD
975	784	82	120	8	100	LYDZ 03-975	07 0885 01	STD
980	784	82	126	8	100	LYDZ 03-980	12-25 0889/2-04951
1016	840	56	76	8	109	LYDZ 03-1016	32 0941 01	SLBP
1022	778	100	24	8	93	LYDZ 03-1022	013.40.900
1047	840	56	69	8	107	LYDZ 03-1047	92-20 0941/07263	法兰
1048	840	56	71	8	107	LYDZ 03-1048	22 0941 01	SL
1048	840	56	71	8	107	LYDZ 03-1048	RKS.22 0941
1048	841	56	75	8	107	LYDZ 03-1048	RK6-37N1Z	法兰
1048	842	56	75	8	107	LYDZ 03-1048	HS6-37N1Z
1048	840	56	71	8	107	LYDZ 03-1048	VLI200944N ZT
1050	794	82	168	8	100	LYDZ 03-1050	02 0935 00	STD
1055	810	80	149	10	83	LYDZ 03-1055	12-25 0955/1-03220
1066	785	85	190	10	79	LYDZ 03-1066	07 0946 05	STD
1100	810	90	164	10	83	LYDZ 03-1100	VLI300955N
1100	812	71	159	10	83	LYDZ 03-1100	92-32 0955/1-06215	法兰
1122	878	100	160	10	83	LYDZ 03-1122	013.40.1000
1166	986	56	92	8	125	LYDZ 03-1166	32 1091 01	SLBP
1166	984	56	91	8	125	LYDZ 03-1166	12-20 1091/1-02272
1170	882	98	258	10	89	LYDZ 03-1170	02 1050 00	STD
1175	961	90	179	10	98	LYDZ 03-1175	07 1075 01	STD
1197	984	56	83	8	125	LYDZ 03-1198	92-20 1091/1-07273	法兰
1198	994	56	85	8	125		RK6-43N1Z	法兰
1198	986	56	80	8	125		22 1091 01	SL
1198	986	56	80	8	125		RKS.22 1091
1198	984	56	83	8	125		92-20 1091/1-07272
1198	994	56	83	8	125		HS6-43N1Z
1198	984	56	80	8	125		VLI201094N ZT
1200	910	90	181	10	93	LYDZ 03-1200	VLI301055N
1200	912	71	176	10	93	LYDZ 03-1200	92-32 1055/1-06225
