External Gear Slewing Bearing Diameter

Brand DZE
Product origin Luoyang China
Delivery time 15-30 days
Supply capacity 2000sets/mouth

DZE Products and Servies.pdf

External gear slewing bearings - outer diameter size, inner diameter 40mm to 1500mm precision bearing manufacturer. External gear slewing bearings are our main products. The precision cross roller bearings we produce are forged with bearing steel GCr15; GCr15SiMn is quenched, tempered and annealed to reach a hardness of HRC56-62, with stable mechanical properties and a service life of more than 10 years. DZE Bearing provides stainless steel and hard aluminum non-standard customized bearings with special requirements. 60% of the precision cross roller bearings are exported to 65 countries; since the company was founded in 2012, we have produced and provided more than 800,000 sets of precision cross roller bearings and precision turntable bearings;

External Slewing Bearing Diameter-slewing bearing outer diameter

External slewing bearing model parameters

External Slewing Bearing-The parameter table is as follows, including bearing outer diameter, inner diameter, and height;

D	d	高度	重量	M	Gear Z	DZE MODEL	Model	备注
135	65	22	1.5	2	70	LYDZ01-135	011.10.100	STD
160	80	27	3.5	2	85	LYDZ01-160	011.10.120	STD
180	40	35	5	4	43	LYDZ01-180	11-16 0100/1-08100	STD
200	100	30	5.5	2	105	LYDZ01-200	011.10.150	STD
234	124.5	36	7.5	2	120	LYDZ01-234	011.10.180	STD
241	122	34	6.8	8	74	LYDZ01-241	16305001	STD
244	125	25	5	2	120	LYDZ01-244	01 0181 02	STD
259.36	135	35	7.5	4	62	LYDZ01-259	VA140188-V	SL
280	140	35	9	4	68	LYDZ01-280-L	11-16 0200/1-08110	STD
280	120	60	17	3	98	LYDZ01-280	011.20.200	STD
304	144	60	20	3	105	LYDZ01-304	011.20.224	STD
312	145	50	17	5/7	60	LYDZ01-312	MTE-145/011.20.222	STD
318	169	45	14	3	104	LYDZ01-318	01 0235 00	STD
318.6	171	40	13	4	78	LYDZ01-618-L	VA160235-N	SL
330	170	60	23	4	86	LYDZ01-330	011.20.250	STD
360	200	60	27	4	94	LYDZ01-360	011.20.280	STD
373	210	40	18	5/7	72	LYDZ01-373	MTE-210/MTE-210T
379	210	45	20	4	92	LYDZ01-379	01 0289 06	STD
380	240	35	14	4	93	LYDZ01-380	11-16 0300/1-08120	STD
384	238	32	14	4	94	LYDZ01-384	VA160302-N	SL
403.5	234	55	25	4.5	88	LYDZ01-403.5	01 0307 00	STD
404	204	56	23	5	79	LYDZ01-404	91-20 0311/1-07102	STD
406.4	233	55	25	5	78	LYDZ01-406.4	16337001	STD
408	222	70	34	5	85	LYDZ01-408	011.25.315	STD
408.4	235	60	29.5	5	80	LYDZ01-408.4	VA250309-N	SL
434	265	50	26	5/7	84	LYDZ01-434-L	MTE-265/MTE-265T	STD
434	260	84	48	5/7	84	LYDZ01-434	16258001	STD
440	265	50	28	4.5	95	LYDZ01-440	01 0342 00	STD
448	262	70	54	5	93	LYDZ01-448	011.25.355	STD
467	290	65	48	5	97	LYDZ01-467	011.25.380	STD
480	340	35	18	4	118	LYDZ01-480	11-16 0400/1-08130	STD
493	307	70	34	5	85	LYDZ01-493	011.25.400	STD
503.3	342	56	31	5	99	LYDZ01-503	RKS.061.20.0414	STD
							VSA200414-N	STD
							31 0411 01	SLBP
504	304	56	30	5	99	LYDZ01-504	VLA200414-N	SL
							231.20.0400.503	SL
							21 0411 01	SL
505.46	304.8	56	38	4	78	LYDZ01-505	HS6-16E1Z	STD
505.46	304.8	56	38	4	78	LYDZ01-505	RK6-16E1Z	SL
520	323.85	52 60	45	5/7	101	LYDZ01-520 MTE-324X	MTE-324T MTE-324X	STD
529	323	54	45	5	103	LYDZ01-529	01 0422 01	STD
535	305	75	61	8	65	LYDZ01-535	06 0400 00	STD
540.66	315.9	71	64	5/7	105	LYDZ01-540	16306001	STD
543	357	70	71	6	94	LYDZ01-543	011.25.450	STD
580	440	35	22	4	143	LYDZ01-580	11-16 0500/1-08140	STD
589	383	75	62	5	116	LYDZ01-589	06 0475 22	STD
590.4	355	80	74	8	72	LYDZ01-590	11-25 0455/1-04110	STD
592.65	349	63	80	6	138	LYDZ01-592	16338001	STD
602	398	80	85	5	123	LYDZ01-602	011.30.500	STD
640	434	56	44	6	105	LYDZ01-640-L	RK6-22E1Z	SL
							231.20.0500.503
							VLA200544
							91-20 0541/1-07122
							21 0541 01	SL
640.3	472	56	43	6	105	LYDZ01-640	31 0541 01	SLBP
							RKS.061.20.0544	STD
							VSA200544-N	STD
654	390	85	98	8	80	LYDZ01-654	06-0508-00	STD
662	458	80	95	5	135	LYDZ01-662	011.30.560	STD
683.26	469.9	60	67	4	106	LYDZ01-683	MTE-470/MTE-470T	STD
689	455	74	89	6	112	LYDZ01-689	01 0555 01	STD
692	534	56	52	4	115	LYDZ01-692	RK6-25E1Z	SL
694.4	455	80	93	8	85	LYDZ01-694	11-25 0555/1-04120	STD
695	477	77	82	5	137	LYDZ01-695	16339001	STD
700	479	77	85	6	114	LYDZ01-700	06-0574-09	STD
732	528	80	110	6	126	LYDZ01-732	011.30.630	STD
740.41	533.4	56	62	4	115	LYDZ01-740	HS6-25E1Z	STD
742.3	572	56	52	6	122	LYDZ01-742	31 0641 01	SLBP
							RKS.061.20.0644
							VSA200644-N	STD
742.3	534	56	50	6	122	LYDZ01-742-L	21 0641 01
							VLA200644-N	SL
							91-20 0641/1-07132	STD
							231.20.0600.503	SL
							231.21.0675.013	SL
							E.750.20.00.C	SL
753	539.75	60	74	4	117	LYDZ01-753	MTE-540/MTE-540T	STD
773.6	482.6	92	150	3.5	105	LYDZ01-773	16307001	STD
774	516	82	118	8	94	LYDZ01-774	01 0626 00	STD
798.4	555	80	111	8	98	LYDZ01-798	11-25 0655/1-04130	STD
812	608	80	120	6	139	LYDZ01-812	011.30.710	STD

816	573	90	129	6	132	LYDZ01-816	06 0675 00	STD
835.7	634	56	58	4	130	LYDZ01-835	HS6-29E1Z	STD
835.7	634	56	58	4	130	LYDZ01-835	RK6-29E1Z	SL
838.1	672	56	59	6	138	LYDZ01-838	RKS.061.20.0744
							31 0741 01
							VSA200744-N	STD
840	634	56	55	6	138	LYDZ01-838-L	VLA200744N	SL
							21 0741 01	STD
							E.850.20.00.C	STD
							231.20.0700.503	SL
851.76	587	73	129	3	99	LYDZ01-851	MTE-590/MTE-590T	STD
854	673.99	56	64	8	105	LYDZ01-854	16340001	STD
863	679	82	102	6	142	LYDZ01-863	01 0765 01	STD
886	610	85	155	8	108	LYDZ01-886	06 0734 00	STD
898	655	80	125	9	98	LYDZ01-898	11-25 0755/1-04140	STD
910	609	88.9	181	2.5	88	LYDZ01-910	HT10-30E1Z	STD
922	678	100	220	8	118	LYDZ01-922	011.40.800	STD
923	622.3	119	263	6	216	LYDZ01-923	16341001	STD
944.88	734	56	69	3	110	LYDZ01-944	RK6-33E1Z	SL
944.88	734	56	69	3	110	LYDZ01-944	HS6-33E1Z	STD
950	772	56	71	8	117	LYDZ01-950	31 0841 01	SLBP
							RKS.061.20.0844
							VSA200844-N	STD
950.1	734	56	65	8	117	LYDZ01-950-L	VLA200944N	SL
							21 0841 01 231.20.0800.503
							231.21.0875.013	SL
							E.950.20.00.C	SL
970.3	704.85	73	148	3	113	LYDZ01-970	MTE-705/MTE-705T	STD
979	717	100	178	10	94	LYDZ01-979	06 0823 18	STD
997	755	80	145	9	109	LYDZ01-997	11-250855/1-03110	STD
1000.76	749	98	177	4	156	LYDZ01-1000	12440001	STD
1022	770	82	159	8	125	LYDZ01-1022-L	01 0880 00	STD
1022	778	100	240	8	130	LYDZ01-1022	011.40.900	STD
1046	834	56	76	8	129	LYDZ01-1046	21 0941 01	SL
1046.1	834	56	75	8	129		RK6-37E1Z	STD
1046.1	834	56	75	8	129		91-200941/1-07163
1046.4	834	56	75	8	129		VLA200944	STD
1046.1	872	56	77	8	129	LYDZ01-1046	VSA200944
							RKS.061.20.0944	STD
							31 0941 01	STD
1062.99	730	83	223	2.5	103	LYDZ01-1062	MTE-730 MTE-730T	STD
1094	833	82	179	8	134	LYDZ01-1094	01 0947 00	STD
1096	855	80	171	9	120	LYDZ01-1096	11-25 0955/1-03120	STD
1096.2	805	90	165	9	120	LYDZ01-1096-L	91-32 0955/1-06115	STD
1122	878	100	270	10	116	LYDZ01-1122	011.40.1000	SL
1144	869	100	228	10	111	LYDZ01-1144	06 0980 09	SLBP
1198	984	56	86	8	148	LYDZ01-1198	21 1091 01	STD
1198	984	56	86	8	148	LYDZ01-1198	VLA201094
1198	1022	56	91	8	148	LYDZ01-1198-L	31 1091 01	STD
1198.1	1022	56	91	8	148		RKS.061.20.1094	STD
1198.4	1022	56	90	8	148		11-201091/1-02172	STD
1198.4	1022	56	90	8	148		11-201091/1-02173	STD
1218	930	98	268	10	119	LYDZ01-1218	01 1050 00	STD
1289.5	984	114	330	10	125	LYDZ01-1289	06 1116 00	STD
1358	1045	98	325	10	133	LYDZ01-1358	01 1180 00	STD
1431	1200	63	176	8	177	LYDZ01-1431	01 1295 01	STD
1476	1084	110	503	10	144	LYDZ01-1476	06 1250 21	STD
1604	1206	130	653	10	157	LYDZ010-1604	06 1390 03	STD
1605	1270	110	469	12	131	LYDZ01-1605	01 1410 00
1727	1500	63	213	8	214	LYDZ01-1727	01 1595 00
